From cells to protein, end to end
Improving access to cell-free protein synthesis
Hover over or tap any step to see what we changed and the papers behind it.
Reaction inputs
Growth
Growing the E. coli source strain. Reformulating the growth media activates the cells’ energy metabolism, which makes a 24-hour workflow from cells to protein possible, and autoinduction removes the manual induction step.
Read the papers
- Activation of Energy Metabolism through Growth Media Reformulation Enables a 24-Hour Workflow for Cell-Free Expression (opens in a new tab)Levine et al. · ACS Synthetic Biology · 2020
- From Cells to Cell-Free Protein Synthesis within 24 Hours Using Cell-Free Autoinduction Workflow (opens in a new tab)Smith et al. · JoVE · 2021
Harvest and wash
Cells are collected by centrifugation and washed before lysis. Our protocols lay out each step so new users can prepare extract reliably.
Read the papers
- Escherichia coli-Based Cell-Free Protein Synthesis: Protocols for a Robust, Flexible, and Accessible Platform Technology (opens in a new tab)Levine et al. · JoVE · 2019
- A User’s Guide to Cell-Free Protein Synthesis (opens in a new tab)Gregorio, Levine, and Oza · Methods and Protocols · 2019
Lysis
Breaking the cells open releases their transcription and translation machinery. We describe simple, robust ways to prepare active extract.
Read the papers
- Simple Extract Preparation Methods for E. coli-Based Cell-Free Expression (opens in a new tab)Mullin, Slouka, and Oza · Methods in Molecular Biology · 2022
Post-lysis processing
Clarifying and conditioning the lysate turns it into active extract. Changes at this stage extended extract shelf life and raised productivity. Mixing extracts with different strengths, such as chaperone-enriched and oxidative-folding extracts, tunes the folding environment for difficult proteins.
Read the papers
- Unlocking Applications of Cell-Free Biotechnology through Enhanced Shelf Life and Productivity of E. coli Extracts (opens in a new tab)Gregorio et al. · ACS Synthetic Biology · 2020
- Modular Cell-Free Extract Mixing Enables Soluble, Active Biomanufacturing of Difficult-to-Express and Aggregation-Prone Proteins (opens in a new tab)Firmansyah, Delmundo, and Oza · bioRxiv preprint · 2026
Cell-free protein synthesis reaction
Extract, a DNA template, and reaction components are mixed, and transcription and translation run in a tube. We characterized reaction kinetics and found ways to reach full yield faster.
Read the papers
- Characterizing and Improving Reaction Times for E. coli-Based Cell-Free Protein Synthesis (opens in a new tab)Burrington, Watts, and Oza · ACS Synthetic Biology · 2021
- Escherichia coli-Based Cell-Free Protein Synthesis: Protocols for a Robust, Flexible, and Accessible Platform Technology (opens in a new tab)Levine et al. · JoVE · 2019
Protein product
The finished protein is ready in hours, without keeping cells alive, for testing, teaching, or downstream use.
Read the papers
- Cell-Free Gene Expression (opens in a new tab)Smith, Dopp, Reuel, and Oza · Handbook of Molecular Biotechnology · 2024
- Biotechnology Applications of Cell-Free Expression Systems (opens in a new tab)Brookwell, Oza, and Caschera · Life · 2021
AI-guided design
AI protein-design and structure-prediction tools can propose new sequences. Written into a DNA template, each design goes straight into a cell-free reaction, a fast way to build and test computational designs.
DNA template
The genetic instructions for the protein. We characterized and improved pET vectors for cell-free expression, and reviewed ways to protect linear DNA templates so they can be used directly.
Read the papers
- Characterizing and Improving pET Vectors for Cell-Free Expression (opens in a new tab)Jew et al. · Frontiers in Bioengineering and Biotechnology · 2022
- Established and Emerging Methods for Protecting Linear DNA in Cell-Free Expression Systems (opens in a new tab)Fochtman and Oza · Methods and Protocols · 2023
Cofactors and substrates
Amino acids, nucleotides, and cofactors supply the building blocks for transcription and translation.
Read the papers
- A User’s Guide to Cell-Free Protein Synthesis (opens in a new tab)Gregorio, Levine, and Oza · Methods and Protocols · 2019
Energy and salts
An energy regeneration system and tuned salts keep the reaction running. Reaction additives can shorten the time to full yield.
Read the papers
- Characterizing and Improving Reaction Times for E. coli-Based Cell-Free Protein Synthesis (opens in a new tab)Burrington, Watts, and Oza · ACS Synthetic Biology · 2021
- A User’s Guide to Cell-Free Protein Synthesis (opens in a new tab)Gregorio, Levine, and Oza · Methods and Protocols · 2019
Solid-state storage
Storing cell-free systems in solid form, so reactions can travel and work outside the lab.
Read the papers
- Development of Solid-State Storage for Cell-Free Expression Systems (opens in a new tab)Brookwell et al. · ACS Synthetic Biology · 2023
Improved workflow
From growth to lysis, our changes bring the time from cells to active extract down to about a day.
Read the papers
- Activation of Energy Metabolism through Growth Media Reformulation Enables a 24-Hour Workflow for Cell-Free Expression (opens in a new tab)Levine et al. · ACS Synthetic Biology · 2020
- From Cells to Cell-Free Protein Synthesis within 24 Hours Using Cell-Free Autoinduction Workflow (opens in a new tab)Smith et al. · JoVE · 2021
- Simple Extract Preparation Methods for E. coli-Based Cell-Free Expression (opens in a new tab)Mullin, Slouka, and Oza · Methods in Molecular Biology · 2022
Enhanced shelf life and productivity
Extract that keeps its activity longer and makes more protein, the step that led to solid-state storage.
Read the papers
- Unlocking Applications of Cell-Free Biotechnology through Enhanced Shelf Life and Productivity of E. coli Extracts (opens in a new tab)Gregorio et al. · ACS Synthetic Biology · 2020
- Development of Solid-State Storage for Cell-Free Expression Systems (opens in a new tab)Brookwell et al. · ACS Synthetic Biology · 2023
Improved reaction rates
Characterizing reaction kinetics and the additives that bring a reaction to full yield sooner.
Read the papers
- Characterizing and Improving Reaction Times for E. coli-Based Cell-Free Protein Synthesis (opens in a new tab)Burrington, Watts, and Oza · ACS Synthetic Biology · 2021
What it enables
Education
Hands-on biology in the classroom, from the open-source Genetic Code Kit to a low-cost, portable incubator-illuminator.
Read the papers
- The Genetic Code Kit: An Open-Source Cell-Free Platform for Biochemical and Biotechnology Education (opens in a new tab)Williams et al. · Frontiers in Bioengineering and Biotechnology · 2020
- The Fold-Illuminator: A Low-Cost, Portable, and Disposable Incubator-Illuminator Device (opens in a new tab)Burrington et al. · Synthetic and Systems Biotechnology · 2021
Post-translational modifications
Proteins carrying chemical modifications added during or after synthesis, including site-specific phosphorylation built in during cell-free synthesis and disulfide bonds formed by an oxidative folding extract.
Read the papers
- Modular Cell-Free Extract Mixing Enables Soluble, Active Biomanufacturing of Difficult-to-Express and Aggregation-Prone Proteins (opens in a new tab)Firmansyah, Delmundo, and Oza · bioRxiv preprint · 2026
- Robust Production of Recombinant Phosphoproteins Using Cell-Free Protein Synthesis (opens in a new tab)Oza et al. · Nature Communications · 2015
- Biotechnology Applications of Cell-Free Expression Systems (opens in a new tab)Brookwell, Oza, and Caschera · Life · 2021
Difficult-to-express proteins
Proteins that are toxic to cells or hard to fold inside them. Mixing specialized extracts made the aggregation-prone toxin colicin M and a truncated human tissue plasminogen activator more than 95 percent soluble while keeping them active.
Read the papers
- Modular Cell-Free Extract Mixing Enables Soluble, Active Biomanufacturing of Difficult-to-Express and Aggregation-Prone Proteins (opens in a new tab)Firmansyah, Delmundo, and Oza · bioRxiv preprint · 2026
- Biotechnology Applications of Cell-Free Expression Systems (opens in a new tab)Brookwell, Oza, and Caschera · Life · 2021
Diagnostics
Low-cost diagnostic tests built from cell-free systems.
Read the papers
- Development of Next-Generation Diagnostic Tools Using Synthetic Biology (opens in a new tab)Vojvoda, Burrington, and Oza · New Frontiers and Applications of Synthetic Biology · 2022
- Biotechnology Applications of Cell-Free Expression Systems (opens in a new tab)Brookwell, Oza, and Caschera · Life · 2021
Synthetic cells
Students design and build synthetic cells from the bottom up, in the Engineering Synthetic Cells course and on the Cal Poly iGEM team that the lab mentors.
High-throughput
Testing many designs in parallel in small reactions.
Read the papers
- Biotechnology Applications of Cell-Free Expression Systems (opens in a new tab)Brookwell, Oza, and Caschera · Life · 2021
Virus-like particles
Self-assembling protein shells, for example for vaccines.
Read the papers
- Biotechnology Applications of Cell-Free Expression Systems (opens in a new tab)Brookwell, Oza, and Caschera · Life · 2021
Large-scale
Scaling reactions up to make more protein.
Read the papers
- Biotechnology Applications of Cell-Free Expression Systems (opens in a new tab)Brookwell, Oza, and Caschera · Life · 2021
Membrane proteins
Proteins that sit in lipid membranes and are hard to make in living cells.
Read the papers
- Biotechnology Applications of Cell-Free Expression Systems (opens in a new tab)Brookwell, Oza, and Caschera · Life · 2021
